Monocrystalline Solar Module (54 cells)

Discover the QingTian Alt Black Monocrystalline Solar Module, the – CEC6-54MHV.

  • Easy to install
  • Outstanding cost-effectiveness
  • Optimal performance even under low light conditions

Loading...

Double-sided energy production

Guaranteed performance

Maximum efficiency even in low light conditions

Monocrystalline Solar Module (54 cells)

Technical description

OUTSTANDING PERFORMANCE

The latest innovation from CECEP Solar, the CEC6-54MHV monocrystalline silicon solar module, offers an exceptionally high performance of 400-415W. It provides maximum efficiency even under low light conditions.


EFFICIENCY

  • Easy to install
  • Outstanding cost-effectiveness
  • Optimal performance even under low light conditions

RELIABILITY

Internationally recognized certifications such as IEC61215 and IEC61730, as well as CE marking.

WHO WE
RECOMMEND IT TO?

This module is a perfect choice for customers looking for high efficiency and durability

LINEAR WARRANTY
AND CERTIFICATION

  • Performance does not drop below 98% in the first year
  • 12-year warranty on materials and performance
  • Performance does not drop below 91.95% within 12 years
  • Performance does not drop below 84.8% within 25 years


For more information, please contact us!

More

CECEP-54 MHV

MECHANICAL CHARACTERISTICS
Cell type
182*91 mm monocrystalline silicon solar cells, 108 cells (6*18)
Glass
3.2 mm thick low-iron tempered glass with light transmittance
IP grade
IP68
Temperature rating
Nominal Module Operating Temperature
42°C +/- 2°C
Max. Power Temperature Coefficient (%/°C)
-0.34
Open-Circuit Voltage Temperature Coefficient (%/°C)
-0.26
Short Circuit Current Temperature Coefficient (%/°C)
0.05
Limit Parameters
-40°C – +85°C
25 A
Mechanical Parameters
Dimension
1722*1134*30 mm
Mounting hole size
1150*1088, 1400*1088 mm
Cable Length
300 mm; costumizable
Weight
21.5 kg
Mode of Packing
40 ’HQ container
36 pcs/pallet
26 pallet/40’HQ (container)
936 pcs/40’HQ (container)
Modul paraméterek
Electrical parameters
CEC-54-400MH CEC-54-400MHV
CEC-54-405MH CEC-54-405MHV
CEC-54-410MH CEC-54-410MHV
CEC-54-415MH CEC-54-415MHV
Max. power
400
405
410
415
Max. operating voltage
31.9
31.26
31.42
31.61
Max. operating current
12.86
12.96
13.05
13.13
Open-circuit voltage
37.00
37.20
13.84
13.94
Short-circuit voltage
13.65
13.76
13.84
13.94
Max. system voltage
1000/1500
1000/1500
1000/1500
1000/1500
Module efficiency
20.5%
20.7%
20.9%
21.1%
Power
0/+5W
0/+5W
0/+5W
0/+5W
Measured values under STC
Parameters measured under nominal test conditions
