Monocrystalline Solar Module (72 cells)

The latest innovation from CECEP Solar, the CEC6-72MHV monocrystalline silicon solar module, boasts an impressive power output of 530-555W.

Loading...

Double-sided energy production

Guaranteed performance

Optimal efficiency even under low light conditions

Monocrystalline Solar Module (72 cells)

Technical Description

EXCEPTIONAL PERFORMANCE

The latest breakthrough from CECEP Solar, the CEC6-72MHV monocrystalline silicon solar module, delivers an outstanding power output of 530-555W.

EFFICIENCY

  • 20.5%-21.5% efficiency
  • Guaranteed performance
  • Double-sided energy production
  • Optimal efficiency even in low light conditions

RECOMMENDED FOR

Thanks to its lightweight, easy installation, and excellent quality and reliability, this product is ideal for those seeking simplicity and cost-effectiveness in solar energy utilization.

RELIABLE
AND SAFE

The IP68 rating ensures exceptional reliability and durability, as well as resistance to extreme wind and snow loads

LINEAR WARRANTY AND CERTIFICATION

  • Performance does not drop below 98% in the first year
  • 12-year warranty on materials and performace
  • Performance does not drop below 91.95% within 12 years
  • Performance does not drop below 84.8% within 25 years

For more information, please contact us!

Contact

CECEP-72 MHV

MECHANICAL CHARACTERISTICS
Cell type
182*91 mm monocrystalline silicon solar cells, 144 cella (6*24)
Glass
3.2 mm thick low-iron tempered glass with light transmittance
IP grade
IP68
Temperature rating
Nominal Module Operating Temperature
42°C +/- 2°C
Max. Power Temperature Coefficient (%/°C)
-0.34
Open-Circuit Voltage Temperature Coefficient (%/°C)
-0.26
Short Circuit Current Temperature Coefficient (%/°C)
0.05
Limit Parameters
Operating temperature
-40°C – +85°C
Maximum fuse current rating
25 A
Physical Parameters
Dimension
2278*1134*35 mm
Mounting hole size
400*1092, 990*1089, 1400*1089 mm
Cable Length
250 mm; costumizable
Weight
28.3 kg
Mode of Packing
40 ’HQ container
31 pcs/pallet
20 pallet/40’HQ (container)
620 pcs/40’HQ (container)
Parameters of Module
Electrical parameters
CEC-72-530MH CEC-72-530MHV
CEC-72-535MH CEC-72-535MHV
CEC-72-540MH CEC-72-540MHV
CEC-72-545MH CEC-72-545MHV
CEC-72-550MH CEC-72-550MHV
CEC-72-555MH CEC-72-555MHV
Max. power
530
535
540
545
550
555
Max. operating voltage
41.67
41.97
42.13
42.42
42.71
42.99
Max. operating current
12.72
12.75
12.82
12.82
12.88
12.91
Open-circuit voltage
49.64
49.71
49.91
50.02
50.14
50.26
Short-circuit voltage
13.48
13.52
13.58
13.62
13.68
13.72
Max. system voltage
1000/1500
1000/1500
1000/1500
1000/1500
1000/1500
1000/1500
Module efficiency
20.5%
20.7%
20.9%
21.1%
21.3%
21.5%
Power
0/+5W
0/+5W
0/+5W
0/+5W
0/+5W
0/+5W
Measured values under STC
